Structural design

The structural design in Focus Engineering is performed in accordance with our clients’ specifications and within the requirements as given by the applicable design standards. We have a high focus on weight optimization and fabrication-friendly design.

Depending on the task, we use various CAD design tools. For larger structures our main software is Bentley ProSteel, whereas for smaller structures and/or mechanical design we use Onshape. All of our structural drawings are based on the structural 3D model, i.e. what you see in the model is what you will also find in the drawings.

For the structural analyses, we do all analysis work in-house. Beam models, such as topside modules, are analysed using SAP2000. Detail calculations and analyses for mechanical components are performed using ANSYS Workbench. Based on the given design condition we will find what is the appropriate type of analysis to use. In addition to linear elastic analyses we also do non-linear material definitions, time/history analyses (typically for blast response analyses) and explicit dynamic analyses (impact).

For the most complex analyses we use our ANSYS license through the Rescale platform, which is a cloud-based service that lets us set up a high-performance virtual desktop in order to reduce the analysis time.

We design for

  • In-place
  • Load-out
  • Lifting
  • Transport incl. seafastening
  • Fatigue
  • Explosion
  • Vibration/resonance

We perform

  • Linear-elastic static analyses
  • Non-linear analyses
  • Material nonlinearities
  • Dynamic loading
  • Time/history analyses
  • Explicit analysis
  • Fatigue verification

We use

  • DNVGL standards
  • ABS standards
  • NORSOK standards
  • Eurocode standards
  • IGC code
  • API

Would you like to learn more about Structural Design?
